Switch Linksys Lgs326p Gigabit 24 Puertos Poe+ Sfp

Descripción

LINKSYS LGS326P 26-PORT BUSINESS GIGABIT SMART SWITCH POE+

- Integrated Power Over Ethernet Plus
- Proven Performance and Reliability
- Easy Configuration and Management
- Advanced Network Security
- IPv6 Support
- Enhanced QoS
- Enhanced Security
- Meets EEE (Energy Efficient Ethernet) 802.3az standard

ESPECIFICACIONES
Model Name:
LGS326P

Network Standards:
IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3z
IEEE 802.3x
IEEE 802.3ad
IEEE 802.3az
IEEE 802.3af
IEEE 802.3at
IEEE 802.1d
IEEE 802.1q/p
IEEE 802.1X

Number of Ports with PoE+ Support:
24

Memory:
128 MB

LEDs:
System (blue), Link/Act/PoE (green/green)

System Power Consumption without PoE+:
110V:28.58W,
220V:26.67W

Forwarding Rate:
38.69 Mpps

Switching Capacity:
52 Gbps

MAC Address Table Size:
8K

Jumbo Frame (FE, GE):
9K

Fans:
Two, 8,200 rpm

Dimensions (LxWxH):
440 x 200 x 44 mm (17.3 x 7.9 x 1.7 in.)

Weight:
3.096 kg (6.81 Ibs.)
Power Dedicated to PoE+:
192 W

Power Input:
100–240V
50-60 Hz
(3.5A max)

Operating Temperature:
0 to 50°C (32 to 122°F)

Storage Temperature:
-40 to 70°C (-40 to 158°F)

Storage Humidity:
10 to 90% RH (non-condensing)

Spanning Tree:
IEEE 802.1d Spanning Tree, IEEE 802.1w Rapid Spanning Tree

Link Aggregation:
IEEE 802.3ad LACP, up to 4 groups with up to 8 ports per group

VLAN:
Port-based and 802.1q tag-based VLANs, Management VLAN, Guest VLAN support, Dynamic VLAN assignment via Radius server with 802.1x client authentication

Number of VLANs Supported:
128 active VLANs (4,096 range)

Auto Voice VLAN:
VLAN Voice traffic is automatically assigned by OUI to a voice-specific VLAN and treated with appropriate levels

IGMP Snooping:
IGMP (v1/v2/v3) snooping provides for fast client joins and leaves of multicast streams and limits bandwidth-intensive video traffic to only the requestors; supports 256 multicast groups

HOL Blocking Prevention:
Head of line (HOL) blocking prevention

Port Mirroring:
Traffic on multiple ports can be mirrored to another port for analysis with a network analyzer

Security Features:
802.1x Radius authentication
DHCP snooping
IP-MAC binding
Port security supports limited dynamic lock and locked MAC address
Management access control

Storm Control:
Broadcast, flooding, and multicast

RMON:
Embedded remote monitoring (RMON) software agent support for enhanced traffic management, monitoring, and analysis
Management Interface:
http
https

Other Management:
Telnet (Menu CLI), DHCP client, system log, configuration unload and backup via http or TFTP, PING, dual images, SNTP

SNMP:
Version 1
Version 2c

Firmware Upgrade:
Web Browser (http/https)
TFTP

QoS - Class of Service:
Port-based, 802.1p priority-based, IPv4/v6 IP DSCP-based

Combo Ports (RJ45 + SFP):
2 combo on ports g25, g26

Copper FE/GE Ports (RJ45):
g01–g12, g13-g24

Green Power Mode:
EEE+, Short Reach + Energy Detect

QoS - Priority Levels:
4 hardware queues

QoS - Scheduling:
Priority queuing and weighted round robin (WRR)

Total System Ports:
26GE
